Sound permeable and breathable membrane

FSM IP67 EPTFE Pressure Equalization Vent for EV Battery Packs

Name: FSM IP67 EPTFE Pressure Equalization Vent for EV Battery Packs
Brand: Meetall
SKU: FSM

FSM. Thickness: 0.3mm; Material Feature: EPTFE; Sample Size: 8mm*4mm.

Key attributes

Parameters

Specifications

Material	eptfe
Thickness	0.3mm
Material Feature	EPTFE
Processing Service	Moulding Cutting
Sample Size	8mm*4mm
Place of Origin	Guangdong, China
Model Number	FSM
Brand Name	MEETALL
Size	Customization supported
IP rate	IP-67~IP68
Transmission Loss	1.5db-3db
Service Temperature	Minus 40 degrees to 135 degrees
Air Flow	300~10000
Color	white&black
Total Thickness	0.01mm+Custom Thickness Available
Water Resistance Pressure	>100KPA
shape and size	customizable

Minimum order quantity	100 pieces
Selling Units	Single item
Single package size	25X15X5 cm
Single gross weight	0.5 kg
Lead time	1 - 500 pieces: 7 days; 501 - 5,000 pieces: 10 days; 5,001 - 25,000 pieces: 31 days

Description

Waterproof rating IP67-IP68

Sound loss of 1.5dB-3.5dB

Ventilation speed 300-10000mm/S

Pressure resistance of 5-100 meters

Customizable size and thickness, customizable with different adhesives
