Condensation inside sealed boxes
Module vents let the housing equalize pressure, so moisture is not pulled in through the seals.
Industrial & IoT Sensors
Module vents, cover gaskets, conductive die-cuts, and foam for outdoor sensors and sealed industrial electronics.
Application
Keep sealed modules breathing, quiet, and dry
A sensor in a cabinet, on a pole, or inside a machine lives with pressure swings, dust, condensation, and radio noise. The housing is sealed to keep the weather out, which means it needs a controlled way to breathe.
The module vent is the construction Meetall cuts for that box. Around it sit the gaskets that seal the cover, the foam that steadies the board, conductive pieces that keep a reading quiet, and FPC stiffeners when the sensor is built on a flex.
Industrial lots are smaller and longer-lived than consumer ones. Flatbed presses suit those lots, and the tool can be held for repeat orders years later.
Typical devices
- Outdoor sensors
- Smart meters
- Gateways
- RFID readers
- Control cabinets
- Handheld terminals
- Class 10,000Cleanroom die-cutting
- 5 linesPrecision registration
- LaserFirst article before steel
- 30 daysStated lead time
Page updated
- Since 2015Converting in Dongguan
- 36 machinesPresses, laminators, slitters, testers
- 1,000 m²Plant floor in Dalingshan
- Onsite checkVerified on the Alibaba store
Part map
Where our parts sit in the assembly
Each card is one die-cut job: where it goes, what it has to do, and the material family it is cut from. Point at a card to find it in the stack.
- Enclosure lid
- Cover gasket 02
- Display or label
- Mounting adhesive 05
- Board
- Conductive die-cut 03
- Foam pad 04
- Sensor flex
- FPC stiffener 06
- Enclosure wall
- Module vent 01
-
Module vent
Housing wall of sealed sensors and controllers
Equalize pressure while water and dust stay out.
Waterproof Breathable Membrane -
Cover gasket
Lid and cable gland faces
Seal the enclosure, with adhesive or without.
Buffer sealing foam -
Conductive die-cuts
Shield frames and cable exits
Keep interference off the measurement.
EMI conductive foam -
Foam pads
Behind boards and displays
Steady parts against vibration.
PU Cushioning Foam -
Mounting adhesive
Displays, labels, and sub-modules
Bond parts without screws.
Double-sided Adhesive -
FPC stiffener
Flex sensor tails
Hold the connector end rigid.
Selector
Which part does which job
Read across a row to see what a part has to do, and the floor instrument that checks it before the lot ships.
| Part | Seal | Vent | Shield | Bond | Cushion | Stiffen | Checked with |
|---|---|---|---|---|---|---|---|
| 01Module vent | Yes | Yes | No | No | No | No | 2.5D vision, loupe |
| 02Cover gasket | Yes | No | No | No | Yes | No | 2.5D vision |
| 03Conductive die-cuts | No | No | Yes | No | No | No | Resistance, 2.5D vision |
| 04Foam pads | No | No | No | No | Yes | No | 2.5D vision |
| 05Mounting adhesive | No | No | No | Yes | No | No | Peel, tack, holding power |
| 06FPC stiffener | No | No | No | Yes | No | Yes | 2.5D vision, peel |
What the assembly asks for
The problems buyers in this industry bring to the plant, and how the floor handles each one.
Interference on the reading
Conductive die-cuts close the shield path at seams and cable exits. Resistance is checked on the floor.
Vibration and long service
Foam and gaskets are chosen for the gap and the load, then sampled in your housing before tooling.
Small lots, long life
Flatbed tooling suits smaller lots and can be held for repeat orders.
Parts from the plant
Photographed for the company profile. Shapes are customer-specific, so treat them as examples of the work, not stock items.
Delivery formats
Parts arrive the way your line places them
Tell us how the part goes on: by hand, in a fixture, or from a web. Each format below comes from a named machine on the floor.
Kunlun KL-QP-350 sheet cutters × 2
Sheets
Parts kept on a carrier sheet, counted and stacked, for hand placement or low-volume fixtures.
Kunlun KL-FTJ-1300 CNC slitter, Hadesheng rotary
Rolls
Parts cut on a continuous web and wound to width, for long runs and feeders that pull from a roll.
Kunlun and Hongwen laminators × 16
Laminated stacks
Membrane, mesh, foam, or film combined with adhesive and liner before the cut, so one part replaces several.
Han's Laser CMA0604-B-A
Laser samples
First articles cut from the drawing without a tool, for fit trials before steel is committed.
Material families used here
Open a family for constructions, the instruments that check it, and a quote form.
Waterproof Breathable Membrane
FSM-710 ePTFE acoustic membrane: IP68, water resistance above 60 kPa, 1.5 dB transmission loss, -40 to 135 °C. Self-adhesive, cut to the port.
View details
Buffer sealing foam
PORON, Inoue, Nitto, and Migeer foams for cushioning, sealing, and gap filling.
View details
EMI conductive foam
Conductive foam and fabric-over-foam gaskets that ground a housing and close a shield.
View details
PU Cushioning Foam
Poron XRD polyurethane foam: 0.19 g/cm³, 18 A, high energy absorption and fast rebound, stable from -40 to 100 °C. Rolls or die-cut shapes.
View details
Double-sided Adhesive
6010C transparent acrylic double-sided foam tape: 0.76 mm, pressure sensitive, waterproof, no residue, 80 °C long term and 120 °C short term.
View detailsFrom drawing to production lot
The same four steps for every industry on this site. One sales contact from the first sample to repeat orders.
-
Drawing review
Send a PDF, DXF, a marked photo, or the current part. We read the stack-up and name the material.
-
Laser first article
A Han's Laser sampler cuts the first pieces, so fit is judged in your assembly before a tool is made.
-
Tooling and lot
Flatbed presses for shaped parts, the ten-station rotary line for long webs, all in the Class 10,000 room.
-
Inspection and ship
2.5D vision, web inspection, and peel, tack, and holding-power tests before the lot leaves EXW.
Questions buyers ask
If yours is not here, put it in the quote form. We reply within one business day.
Single-layer or multi-layer membrane?
Both are in our profile. A single-layer adhesive membrane is the direct bond on the opening. A multi-layer adhesive membrane builds a thicker stack when the housing needs it. Tell us the housing and the port.
Do you take small orders?
Send the sample quantity and the yearly volume. Flatbed presses suit smaller lots, and the minimum is stated in the quote.
What should we send for a quote?
A drawing or a marked photo, where the part sits, the sample quantity, and the yearly volume. If the material grade is on the print, include it. If not, describe the job the part has to do.
What are the lead time and trade terms?
The stated lead time is 30 days. Trade is EXW. Payment is T/T, PayPal, or cash, in USD, EUR, HKD, or CNY.
Patents and registrations
Our certificates
Granted in China and held by the company: utility model patents from the national patent office, and software copyright registrations from the National Copyright Administration.
- 3Utility model patents
- 2Software copyright registrations
Ask for certificate copies with your quote.
Request a quote
Quote a part for Industrial & IoT Sensors
Four things make the first reply useful.
- Drawing PDF, DXF, or a marked photo of the current part
- Position Where the part sits and what it touches
- Quantity Sample lot, then the yearly volume
- Format Sheets, rolls, or laminated stacks, and how your line places them
