Sound permeable and breathable membrane

FSM-725 White Self-Adhesive Acoustic Vent for Electronics

Name: FSM-725 White Self-Adhesive Acoustic Vent for Electronics
Brand: Meetall
SKU: FSM-725

FSM-725. Total Thickness: 0.025mm+Custom Thickness Available; Air Flow: 2000; Water Resistance Pressure: >50KPA.

Key attributes

Parameters

Specifications

Rubber Product Type	Rubber Stopper
Color	White
Model Number	FSM-725
Processing Service	Cutting, Moulding
Place of Origin	Guangdong, China
Brand Name	MEETALL
Product name	Waterproof Acoustic Membrane
Total Thickness	0.025mm+Custom Thickness Available
Air Flow	2000
Water Resistance Pressure	>50KPA
Protection Level	IP68 (Dust-tight & Water Immersion Resistant)
Moisture Permeability	>5000g/m2.24H
Transmission Loss	1.5dB-3.5dB
Service Temperature	-40 °C-135 °C
Material	ePTFE Membrane + Adhesive + Release Liner

Minimum order quantity	100 pieces
Selling Units	Single item
Single package size	25X15X3 cm
Single gross weight	0.3 kg
Lead time	1 - 500 pieces: 5 days; 501 - 2,000 pieces: 7 days; 2,001 - 5,000 pieces: 10 days

Description

Waterproof Acoustic Membrane: Protects electronics from water damage with IP68 rating.

Durable Adhesive Layer: Provides strong bonding and long-lasting protection.

Breathable Design: Allows moisture to escape while maintaining sound insulation.

Wide Temperature Range: Operates effectively between -40°C and 135°C.

Customizable Thickness: Offers flexibility in thickness adjustment for various applications.
