Sound permeable and breathable membrane

FSM-710 IP67 EPTFE Vent Sticker for Automotive Sensors

Name: FSM-710 IP67 EPTFE Vent Sticker for Automotive Sensors
Brand: Meetall
SKU: FSM-710

FSM-710. Adhesive Type: Acrylic acid; Adhesive Side: Double Sided; Feature: Acrylic.

Key attributes

Parameters

Specifications

Use	Acoustic For Speaker And Horn Anti Dust Vent
Material	EPTFE
Adhesive Type	Acrylic acid
Adhesive Side	Double Sided
Type	Adhesive Sticker
Feature	Acrylic
Design Printing	No Printing
Printing Handling	No Printing
paper core	76
Adhesive	Acrylic
GLUE	Acrylic Adhesive
Place of Origin	Guangdong, China
Thickness	0.01
Model Number	FSM-710
Brand Name	MEETALL
IP rate	IP-67~IP68
Transmission Loss	1.5db-3db
Service Temperature	Minus 40 degrees to 135 degrees
Air Flow	1800~10000
Color	white&black
Total Thickness	0.01mm+Custom Thickness Available
Water Resistance Pressure	>60KPA
Processing Service	Cutting, Moulding
shape and size	customizable

Minimum order quantity	50 pieces
Selling Units	Single item
Single package size	5X4X0.4 cm
Single gross weight	0.01 kg
Lead time	1 - 100 pieces: 5 days; 101 - 500 pieces: 7 days; 501 - 1,000 pieces: 10 days

Description

Waterproof rating IP67-IP68

Sound loss of 1.5dB-3.5dB

Pressure resistance of 5-80 meters

Customizable size, customizable with different adhesives

Ventilation speed 1800-10000mm/S
