Electromagnetic wave shielding material
HP-50 13.56MHz Flexible Absorber Sheet, MagSafe Safe
Description: Electromagnetic wave shielding; Manufacturer Part Number: HP-50; Mounting Type: adhesive backing.
Key attributes
- Model Number MGR-HP50
- Manufacturer Part Number HP-50
- Mounting Type adhesive backing
- Series HP
- Initial permeability 50
- Minimum order 1000 pieces
- Reference price US$0.19 - 0.32 / piece
Parameters
Specifications
Specification
| Description | Electromagnetic wave shielding |
|---|---|
| Brand Name | MEETALL |
| Manufacturer Part Number | HP-50 |
| Type | HP-50 75mm*10mm*0.12mm |
| Place of Origin | Guangdong, China |
| Mounting Type | adhesive backing |
| Series | HP |
| Initial permeability | 50 |
| Recommended frequency band | 10MHz-6GHz |
| Material | Fe Si Al Magnetic Powder + Rubber + Polymer |
| Working temperature range | From minus 20 degrees Celsius to over 120 degrees Celsius |
| Surface resistance | > 1 × 10⁶ |
| Inductance coefficient | Inductance coefficient 500 nH |
| Purpose | EMI shielding,absorb electromagnetic waves |
| Color | Gray / Black / Customized |
| Surface Treatment | Insulating layer / With double-sided tape |
| Processing Service | Moulding, Cutting |
| Model Number | MGR-HP50 |
| Magnetic permeability (u/at 100MHz) | > 25 |
| Thermal conductivity (W/mK) | 0.6 ~ 0.8 |
| Function | Absorbing electromagnetic wave |
Packaging and delivery
| Minimum order quantity | 1000 pieces |
|---|---|
| Selling Units | Single item |
| Single package size | 7.5X1.1X0.12 cm |
| Single gross weight | 0.03 kg |
| Lead time | 1 - 1,000 pieces: 7 days; 1,001 - 5,000 pieces: 12 days; 5,001 - 10,000 pieces: 15 days |
| Sample | 10 USD |
| Delivery time | 7-10 days |
Description
Product description
HP-50 13.56MHz Flexible Absorber Sheet, MagSafe Safe. Description Electromagnetic wave shielding, Manufacturer Part Number HP-50, Mounting Type adhesive backing, Application Electromagnetic wave shielding. Minimum order 1000 pieces.
