Electromagnetic wave shielding material
Fe-Si-Al Magnetic Sheet 13.56MHz with Thermal Conductive Tape
Description: Electromagnetic; Manufacturer Part Number: HP-250; Mounting Type: adhesive backing.
Key attributes
- Description Electromagnetic
- Manufacturer Part Number HP-250
- Mounting Type adhesive backing
- Series HP
- Features Electromagnetic
- Minimum order 10 pieces
- Reference price US$0.14 - 0.82 / piece
Parameters
Specifications
Specification
| Description | Electromagnetic |
|---|---|
| Brand Name | MEETALL |
| Manufacturer Part Number | HP-250 |
| Type | HP-250 85mm*53mm*0.35mm |
| Place of Origin | Guangdong, China |
| Mounting Type | adhesive backing |
| Application | Electromagnetic |
| Series | HP |
| Features | Electromagnetic |
| Initial permeability | 250 |
| Recommended frequency band | 10MHz-6GHz |
| Material | Fe Si Al Magnetic Powder + Rubber + Polymer |
| Working temperature range | From minus 20 degrees Celsius to over 120 degrees Celsius |
| Surface resistance | > 1 × 10⁶ |
| Inductance coefficient | Inductance coefficient 500 nH |
| Purpose | EMI shielding,absorb electromagnetic waves |
| Color | Gray / Black / Customized |
| Surface Treatment | Insulating layer / With double-sided tape |
| Delivery time | 7-10 days |
Packaging and delivery
| Minimum order quantity | 10 pieces |
|---|---|
| Selling Units | Single item |
| Single package size | 0.86X0.73X0.14 cm |
| Single gross weight | 0.3 kg |
| Lead time | 1 - 100 pieces: 7 days; 101 - 5,000 pieces: 9 days; 5,001 - 10,000 pieces: 12 days |
Description
Product description
Fe-Si-Al Magnetic Sheet 13.56MHz with Thermal Conductive Tape. Description Electromagnetic, Manufacturer Part Number HP-250, Mounting Type adhesive backing, Application Electromagnetic. Minimum order 10 pieces.
